Ventilation pipes made of PVC-U or PVC-C

Our PVC-U or PVC-C ventilation pipes are used for the construction of ventilation systems. Plasticizer-free (PVC-U) or post-chlorinated polyvinyl chloride (PVC-C) is used in production.

Material

  • plasticiser-free polyvinyl chloride (PVC-U)
  • or post-chlorinated polyvinyl chloride (PVC-C)

Versions

  • single-layer solid-wall pipe
  • with smooth ends

Colours

  • PVC-U:
    • dark grey (similar to RAL 7011)
    • or white (similar to RAL 9010)
  • PVC-C:
    • grey (similar to RAL 7035)

Internal operating pressure

  • no pressure pipe

Operating temperature

  • up to 40°C (PVC-U)
  • up to 60°C (PVC-C)

Outer diameters

  • 110 up to 600 mm

SDR levels

Lengths

  • 5 m bars
  • special lengths on request

Packaging

  • pallets
dimensions see here
dimensions see here

Connection techniques

Installation types

  • inside industrial systems and buildings

Labeling

  • with black meter marking
  • special marking on request

Certifications

Standards & guidelines

  • DIN 8062
  • DIN 4740 part 1
  • DIN 4102 B1 (flame retardant up to a wall thickness of 4 mm)
  • EN 13501 (classification of fire behaviour, proofed by LNE, Paris)

Application examples

Material qualities

Advantages

Fittings

Reality shows: you can't just plan pipes strictly straight ahead, you also have to think regularly around the bend! Optimal fittings for every requirement are therefore an integral part of our product range.
